[Ditron-tech] YG600+CL180 Gear Pump

Name: [Ditron-tech] YG600+CL180 Gear Pump
Brand: Ditron-tech
Price: 2622400 KRW
Availability: InStock

가격문의(상세정보 참조)

Model: YG600+CL180

Max Flow : 2.7-18L/min

Max Speed: 90-600rpm

상품

원산지 CHINA

적립

26,224 포인트 적립예정 적립예정

배송

택배 · 기본 무료 · 도서산간 배송비 popover

120,000원 이상 구매 시 무료배송

구매평

Q&A

반품/교환

구매평

Q&A

반품/교환

상품이 없습니다.

Rotational speed range	90-600rpm
Flow Range	2.7-18L/min
Export pressure	10Bar
Display function	Display the rotational speed proportion, showing numbers from 0 to 100, where a value of 100 indicates full speed—equivalent to 600 rpm.
Control Mode	PWM DC Motor Control Technology
Flow regulation	The potentiometer knob adjusts the motor speed, thereby controlling the flow rate.
Direction Control	Liquid transfer direction is reversible.
Electric motor	Brand DC gear motor drive, long lifespan
Power consumption	<300W
Applicable Power Source	AC 200–260V, 50Hz/60Hz
Work environment	0–40°C, humidity below 80% with no condensation
Weight	9.5kg
Protection Level	IP31

Drive	Applicable pump head	Rotational Speed Range (RPM)	Flow rate (mL/rev)	Flow Range (L/min)	Outlet Pressure (Bar)
YG600	CL180	90-600	300	2.7–18	10

Rotational speed range	90-600rpm
Flow Range	2.7-18L/min
Export pressure	10Bar
Display function	Display the rotational speed proportion, showing numbers from 0 to 100, where a value of 100 indicates full speed—equivalent to 600 rpm.
Control Mode	PWM DC Motor Control Technology
Flow regulation	The potentiometer knob adjusts the motor speed, thereby controlling the flow rate.
Direction Control	Liquid transfer direction is reversible.
Electric motor	Brand DC gear motor drive, long lifespan
Power consumption	<300W
Applicable Power Source	AC 200–260V, 50Hz/60Hz
Work environment	0–40°C, humidity below 80% with no condensation
Weight	9.5kg
Protection Level	IP31

Drive	Applicable pump head	Rotational Speed Range (RPM)	Flow rate (mL/rev)	Flow Range (L/min)	Outlet Pressure (Bar)
YG600	CL180	90-600	300	2.7–18	10
